PN Single Stage Single Suction Mud Pump

PN Single Stage Single Suction Mud Pump

The structure of pumps 、 long service life suitable for handling abrasive and corrosive solids-bearing slurry 。

  • Tel:
  • 400-926-5000
  • Product Parameters

DESCRIPTION:

type of PN pump is a single-stage, single-suction, cantilevered centrifugal slurry pump. The wetted parts of pump are made of wear-resistant alloys. The impellers of 6” and less than 6” slurry pumps are connected with shafts in threads. And those of 8” and more than 8” slurry are connected with shafts in keys. This type of pump have the advance simple structure, is easy for assembling, dismantling, check and maintenance. the structure of pumps 、 long service life suitable for handling abrasive and corrosive solids-bearing slurry 。


Performance and Main Technical Datas of PN Slurry Pump

Type

Capacity
Q(m3/h)

Head
H(m)

Speed
n(r/min)

NPSH
r(m)

Max.eff
η(%)

Power
N(KW)

Weight
(Kg)

Outlet
D(mm)

Power of
shaft

Power of
ass.motor

Suction

Discharge

1PN

7.2
12
16

14
13
12

1430

0.55

21
30
35

1.3
1.41
1.5

3

120

50

25

2PN

30
47
58

22
19
17

1450

1.32

33
39
39

5.45
6.25
6.9

11

150

96

50

3PN

54
108
151

26
21
15

1470

2.35

32
42
37

12
14.7
16.7

22

450

125

75

4PN

100
150
200

41
39
37

1470

2.95

46
55
61

24.3
29
33.1

55

1000

150

100

4PN(1)

41.5
80
111

51
50
49

1470

1.92

23
36
44.5

25
30.2
33.1

55

1000

150

100

4PN(2)

52
100
138

51
50
49

1470

2.2

26
37
47

28
37
39

75

1000

150

100

6PN

230
280
320

27
26
25

980

2.59

56
60
62

30.2
33
35.2

75

2.59

200

150





-->
